OEM High Quality 140MM 160MM 168MM 200MM Stainless hlau UPVC Loj Loj Pob Valve Rau Project DN200

Lus piav qhia luv luv:

Pob valve
1.Soft xim & Compact tsim
2.Leakproff ua haujlwm;
3. Lub teeb thiab kev sib koom ua ke xaus ua kom yooj yim installation
4.Kev lag luam raws li tus nqi thauj khoom pheej yig dua & lub neej ua haujlwm ntev
5.Zoo thiab zoo tswj
6. Ib puag ncig tus phooj ywg, tsis muaj tshuaj lom
7.Weathering & Abrasion tsis kam & tshuaj lom neeg zoo heev
8.Widely siv nyob rau hauv lub tsev, irrigation, kev lag luam thiab ua luam dej pas dej ua ke
9.Kev txiav txim me me tau txais
10.Cov neeg siv khoom tsim & logo tau txais tos

Loj:140 hli 160 hli 168 hli 200 hli

Joint End:ASTM BS DIN ISO JIS

Ua haujlwm siab:PIB 16

Xa email rau peb

Product Detail

FAQ

Khoom cim npe

Lus dab neeg thiab daim ntawv qhia lub cev

ib qho kev tsim tawm

Cov khoom siv

specification ntawm cov khoom

TSIS MUAJ.	Ib feem	Khoom siv	QTY
1	Lub cev	UPVC, CPVC	1
2	STEM O-Ring	EPDM, FPM (NBR)	1
3	STEM	UPVC, CPVC	1
4	PIB	UPVC, CPVC	1
5	SEAT SEAL	TPE, TPVC, TPO	2
6	CAP	PVC, ABS	1
7	KUB	PVC, ABS	1
8	SCREW	SS304, hlau	1

Model size parameter sib piv cov lus

DIMENSION												Chav tsev
Qauv	DN		15	20	25	32	40	50	65	80	100
	SIZE		1/2 "	3/4 "	1"	1-1/4 "	1-1/2 "	2"	2-1/2 "	3"	4"	Ntiv
	thd./ ib	NPT	14	14	11.5	11.5	11.5	11.5	8	8	8	mm
	thd./ ib	BSPT	14	14	11	11	11	11	11	11	11	mm
	JIS	I	20	20	24	26	30	31	45	48	53	mm
		d1	22.3	26.3	32.33 Nws	38.43 Nws	48.46 ib	60.56 ib	76.6 ib	89.6 ib	114.7 ib	mm
		d2	21.7 ib	25.7 ib	31.67 Nws	37.57 Nws	47.54 ib	59.44 ib	75.87 ib	88.83 ib	113.98 Nws	mm
	ANSI	I	18	20	24	26	30	31	45	48	53	mm
		d1	21.54 Nws	26.87 Nws	33.65 Nws	42.42 ib	48.56 ib	60.63 ib	73.38 ib	89.31 ib	114.76 ib	mm
		d2	21.23 Nws	26.57 Nws	33.27 Nws	42.04 Nws	48.11 Nws	60.17 Nws	72.85 ib	88.7 ua	114.07 Nws	mm
	DIN	I	18	20	24	26	30	31	45	48	53	mm
		d1	20.3	25.3	32.3	40.3	50.3	63.3 ib	75.3 ib	90.3 ua	110.4 ib	mm
		d2	20	25	32	40	50	63	75	90	110	mm
	d		15	19	24	30	34	45	55	70	85	mm
	H		37	55	66	73	81	91	99	121	134	mm
	A		68	80	94	100	110	136	170	210	236	mm
	L		77	91	103	111	123	146	178	210	255	mm
	D		32	37.5 ib	44	52	60	74	93	110	135	mm
